Conector 4.3-10 Macho Para Cable de 7/8 AVA5-50 y AVA5-50FX
Modelo del producto: A5HM-D
Tipo de produto: Conectores
Interface
|
4.3-10 Male |
Body Style
|
Straight |
Mounting Angle
|
Straight |
Ordering Note
|
CommScope® standard product (Global) |
|
Connector Impedance
|
50 ohm |
Operating Frequency Band
|
0 – 5000 MHz |
Cable Impedance
|
50 ohm |
3rd Order IMD Dynamic Test Method
|
Two +43 dBm carriers |
3rd Order IMD, typical
|
-166 dBc @ 1800 MHz |
3rd Order IMD Test Method
|
Two +43 dBm carriers |
RF Operating Voltage, maximum (vrms)
|
1415.00 V |
dc Test Voltage
|
4000 V |
Outer Contact Resistance, maximum
|
1.50 mOhm |
Inner Contact Resistance, maximum
|
0.40 mOhm |
Insulation Resistance, minimum
|
5000 MOhm |
Average Power
|
3.0 kW @ 900 MHz |
Peak Power, maximum
|
40.00 kW |
Insertion Loss, typical
|
0.05 dB |
Shielding Effectiveness
|
-130 dB |
