Conector DIN 7-16 Macho De Angulo Recto Para Cable FSJ450B

Modelo del producto: F4DR-C

Tipo de produto: Conectores

por ANDREW
Agotado
$ 851.69
Electrical Specifications
Connector Impedance   50 ohm
Operating Frequency Band   0 – 7500 MHz
Cable Impedance   50 ohm
3rd Order IMD, typical   -120 dBm @ 910 MHz
3rd Order IMD Test Method   Two +43 dBm carriers
RF Operating Voltage, maximum (vrms)   884.00 V
dc Test Voltage   2500 V
Outer Contact Resistance, maximum   1.50 mOhm
Inner Contact Resistance, maximum   0.80 mOhm
Insulation Resistance, minimum   5000 MOhm
Average Power   1.0 kW @ 900 MHz
Peak Power, maximum   15.60 kW
Insertion Loss, typical 0.05 dB
Shielding Effectiveness   -110 dB
